FMB965

2G Motorcycle Tracker with Large Internal Battery

Key Features:

2G GSM Connectivity
IP67 Water-Resistant Casing
1200 mAh Internal Backup Battery
Bluetooth 4.0 LE Support
Ultra-Low Power Consumption
POWER OFF SLEEP MODE
Allows to power off module, which enables the power consumption to less than 1mA
IP67 CASING
Reliable protection against dust and water
BACK-UP BATTERY
Enhance device autonomy and minimise vehicle battery drainage
BLUETOOTH® TECHNOLOGY
Bluetooth for external devices and Low Energy sensors
  • Bikes

    Bikes

  • Trailers

    Trailers

  • SUVs

    SUVs

  • Water transport

    Water transport

  • Snowmobiles

    Snowmobiles

The Teltonika FMB965 is a 2G motorcycle tracker designed for reliable tracking in challenging environments, featuring a robust IP67-rated casing that protects against dust and water, making it ideal for motorcycles, boats, jet skis, and trailers. Its large 1200 mAh internal backup battery supports up to 30 days of operation in Power Off Sleep Mode with data transmitted every 4 hours, offering extended autonomous usage without external power. Bluetooth 4.0 LE enables wireless connectivity with external sensors and beacons for monitoring temperature, humidity, magnet detection, and movement, enhancing its suitability for asset protection and rider safety. The innovative clip-on system ensures tool-free installation, adding to its practicality.

FMM13A Side View
FMM13A Front View

This tracker stands out with ultra-low power consumption as low as 1 mA in sleep mode, making it a cost-effective solution for long-term tracking. It supports scenarios like crash detection via its accelerometer and anti-theft features, including jamming detection and vehicle immobilization, which are valuable for preventing theft in open transport vehicles. However, its reliance on 2G networks raises concerns in regions phasing out this technology, potentially affecting future usability. With easy configuration via FOTA Web and compatibility with a wide range of peripherals, the FMB965 delivers excellent value for GPS telematics service providers and end-users.

Technical Specification

Module
Name Teltonika TM2500
Technology GSM/GPRS/GNSS/Bluetooth 4.0 LE
GNSS
Systems GPS, GLONASS, Galileo, BeiDou, QZSS, AGPS
Receiver Tracking: 33 channel
Tracking Sensitivity -165 dBM
Position Accuracy <2.5 m CEP
Hot Start <1 s
Warm Start <25 s
Cold Start <35 s
Cellular
Technology GSM/GPRS
2G Bands Quad-band 850/900/1800/1900 MHz
Data Transfer Up to 85.6 Kbps (DL/UL)
SIM Micro-SIM
Power
Input Voltage Range 6-30 V DC with overvoltage protection
Backup Battery 1200 mAh Li-Ion (up to 30 days in Power Off Sleep Mode)
Power Consumption <1 mA (Power Off Sleep Mode)
Bluetooth
Specification 4.0 + LE
Supported Peripherals Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support
Physical Specifications
Dimensions 89 x 43 x 22 mm
Weight Approximately 100 g
Casing IP67-rated for dust and water resistance
Mounting Clip-on system (tool-free)
Operating Environment
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +85°C
Operating Humidity 5% to 95% non-condensing

Features

Sensors Accelerometer
Inputs/Outputs 1 Digital Input, 2 Digital Outputs
Memory Flash memory (capacity not specified)
Advanced Scenarios Green Driving • Over Speeding detection • Jamming detection
Crash detection • Anti-theft • Static Navigation
Configuration and Firmware Update FOTA Web • Teltonika Configurator
Time Synchronization GPS • NITZ • NTP
Bluetooth Peripherals Temperature and Humidity sensor • Headset
OBDII dongle • Inateck Barcode Scanner • Universal BLE sensors support
