FMC150

Advanced 4G LTE Cat 1 Tracker with CAN Data Processor

Key Features:

4G LTE Cat 1 Connectivity
Integrated CAN Data Processor
Bluetooth 4.0 LE Support
Dual CAN Interfaces
170 mAh Backup Battery
4G CAT 1
Reliable 4G LTE Cat 1 connection with Fallback 2G (GSM) network
CAN DATA FOR EV VEHICLES
CAN module allows data reading from electric vehicles (EV)
INTEGRATED CAN DATA PROCESSOR
Allows to monitor real fuel consumption and level, full mileage, engine temperature and more
NEGATIVE INPUT
Allows easier installation of accessories
  • Electric Vehicles

    Electric Vehicles

  • Light Vehicles

    Light Vehicles

  • Trucks

    Trucks

  • Buses

    Buses

The Teltonika FMC150 is an advanced 4G LTE Cat 1 tracker designed to revolutionize fleet management with its integrated CAN data processor, offering real-time insights into vehicle operations. Ideal for light vehicles, electric vehicles (EVs), trucks, buses, and special machinery, it reads over 40 CAN parameters—including fuel level, total fuel consumption, vehicle speed, and engine RPM—enabling detailed analysis for maintenance and performance optimization. With future-proof 4G LTE connectivity and a fallback to 2G, it ensures reliable network coverage, while Bluetooth 4.0 LE supports integration with external sensors for temperature, humidity, and movement monitoring. Its compact design simplifies installation across diverse fleets.

FMM13A Side View
FMM13A Front View

This 2-in-1 solution combines GPS tracking with CAN data processing, supporting over 100 EV models and 1,500+ vehicle types, making it versatile for logistics, delivery services, and car sharing. Features like green driving, crash detection, and geofencing enhance safety and efficiency, while the 170 mAh backup battery ensures operation during power loss. However, reliance on LTE Cat 1 and 2G fallback may pose challenges in regions transitioning to newer networks, a consideration for long-term planning. Configurable via FOTA Web and equipped with dual CAN interfaces, the FMC150 offers a robust platform for advanced telematics applications.

Technical Specification

Module
Name FMC150-QJIB0: Quectel EG915U-EU with Teltonika TM2500
FMC150-QKIB0: Quectel EG915U-LA with Teltonika TM2500
Technology LTE Cat 1/GSM/GPRS/GNSS/Bluetooth 4.0 LE
GNSS
Systems GPS, GLONASS, Galileo, BeiDou, SBAS, QZSS, DGPS, AGPS
Receiver 33 tracking channels, 99 acquisition channels
Tracking Sensitivity -165 dBM
Position Accuracy <2.5 m CEP
Velocity Accuracy <0.1 m/s (within +/- 15% error)
Hot Start <1 s
Warm Start <25 s
Cold Start <35 s
Cellular
Technology LTE Cat 1, GSM
2G Bands FMC150-QJIB0: B2/B3/B5/B8
FMC150-QKIB0: B2/B3/B5/B8
4G LTE Bands FMC150-QJIB0: LTE FDD: B1/B3/B7/B8/B20/B28
FMC150-QKIB0: LTE FDD: B2/B3/B4/B5/B7/B8/B28/B66
Data Transfer LTE FDD: Max 10 Mbps (DL)/Max 5 Mbps (UL)
LTE TDD: Max 85.6 Mbps (DL)/Max 85.6 Mbps (UL)
GSM GPRS: Max 85.6 Kbps (DL/UL)
Data Support SMS (text/data)
Power
Input Voltage Range 10-30 V DC with overvoltage protection
Backup Battery 170 mAh Li-Ion 3.7 V (0.63 Wh)
Power Consumption At 12V <6 mA (Ultra Deep Sleep)
<8 mA (Deep Sleep)
<11 mA (Online Deep Sleep)
<20 mA (GPS Sleep)
<35 mA (Nominal)
<250 mA Max (Peak)
Bluetooth
Specification 4.0 + LE
Supported Peripherals Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal Bluetooth LE sensors
Physical Specifications
Dimensions 65 x 56.6 x 20.6 mm
Weight Approximately 55 g
Casing IP41-rated for dust and splash resistance
Mounting Flexible mounting options
Operating Environment
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +85°C
Operating Humidity 5% to 95% non-condensing

Features

Inputs/Outputs 3 Digital Inputs, 1 Negative Input (Digital Input 2), 2 Impulse Inputs (Digital Input 1, Digital Input 2), 2 Analog Inputs, 2 Digital Outputs, 2 CAN Interfaces, 1-Wire
Sensors Accelerometer
CAN Data Fuel Level (Dashboard) • Total fuel consumption • Vehicle speed (wheel)
Vehicle driven distance • Engine speed (RPM) • Accelerator pedal position
Supports EV vehicle data reading
Supported Protocols OEM, J1939, IES500, IES125
Advanced Scenarios Green Driving • Over Speeding detection • Jamming detection
GNSS Fuel Counter • DOUT Control Via Call • Excessive Idling detection
Immobilizer • iButton Read Notification • Unplug detection
Towing detection • Crash detection • Auto Geofence • Manual Geofence • Trip
Sleep Modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and Firmware Update FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application
SMS Features Configuration, Events, DOUT control, Debug
GPRS Commands Configuration, DOUT control, Debug
Time Synchronization GPS, NITZ, NTP
Ignition Detection Digital Input 1, Accelerometer, External Power Voltage, Engine RPM
