FMC920

Best-Selling 4G Compact GPS Tracker with Backup Battery

Key Features:

4G LTE Cat 1 Connectivity
Bluetooth 4.0 LE Support
Remote Immobilizer and Crash Detection
Temperature, Humidity, and Liquid Level Monitoring
Integrated 170 mAh Backup Battery
4G CAT 1
Reliable 4G LTE Cat 1 connection with Fallback 2G (GSM) network
BLUETOOTH® TECHNOLOGY
Bluetooth™ LE for external devices and sensors
CRASH DETECTION
Crash detection functionality working according to accelerometer data
BACKUP BATTERY
Allows device to work without external power source
  • Light Vehicles

    Light Vehicles

  • Motorbikes

    Motorbikes

  • Insurance Telematics

    Insurance Telematics

  • Courier Delivery Services

    Courier Delivery Services

  • Rental and Leasing

    Rental and Leasing

The Teltonika FMC920 is a best-selling 4G compact GPS tracker designed for efficient vehicle control, ideal for applications like insurance telematics, rental cars, and delivery transport. Featuring 4G LTE Cat 1 technology with a fallback to 2G, it ensures reliable, future-proof connectivity with higher bandwidth and lower latency. Its slim 12 mm design fits tight spaces, while Bluetooth 4.0 LE enables wireless monitoring of temperature, humidity, and liquid levels via external sensors, enhancing its versatility. The integrated 170 mAh backup battery ensures continuous tracking during power loss, and the remote immobilizer adds a strong anti-theft feature, making it a popular choice for fleet management and public safety.

FMM13A Side View
FMM13A Front View

This tracker supports a wide range of scenarios, including green driving, over-speeding detection, and towing alerts, with a digital input for monitoring ignition, doors, or alarm status. The analog input extends its capabilities to track additional parameters, supported by a 128 MB internal memory storing up to 8,000 records if the GSM signal is lost. However, the reliance on LTE Cat 1 with 2G fallback may pose challenges in regions transitioning to advanced networks, a factor to consider for long-term deployment. Configurable via FOTA Web and Bluetooth, the FMC920 combines compact design with robust functionality for diverse tracking needs.

Technical Specification

Module
Name FMC920-QJIB0: Quectel EG915U-EU with Teltonika TM2500
FMC920-QKIB0: Quectel EG915U-LA with Teltonika TM2500
Technology LTE Cat 1/GSM/GPRS/GNSS/Bluetooth 4.0 LE
GNSS
Systems GPS, GLONASS, Galileo, BeiDou, SBAS, QZSS, DGPS, AGPS
Receiver 33 tracking channels, 99 acquisition channels
Tracking Sensitivity -165 dBM
Position Accuracy <2.5 m CEP
Velocity Accuracy <0.1 m/s (within +/- 15% error)
Hot Start <1 s
Warm Start <25 s
Cold Start <35 s
Cellular
Technology LTE Cat 1, GSM
2G Bands FMC920-QJIB0: B2/B3/B5/B8
FMC920-QKIB0: B2/B3/B5/B8
4G LTE Bands FMC920-QJIB0: LTE FDD: B1/B3/B7/B8/B20/B28
FMC920-QKIB0: LTE FDD: B2/B3/B4/B5/B7/B8/B28/B66
Data Transfer LTE FDD: Max 10 Mbps (DL)/Max 5 Mbps (UL)
GSM GPRS: Max 85.6 Kbps (DL/UL)
Data Support SMS (text/data)
Power
Input Voltage Range 6-30 V DC with overvoltage protection
Backup Battery 170 mAh Li-Ion 3.7 V (0.63 Wh)
Power Consumption At 12V < 2 A Max. (with full load/peak)
Bluetooth
Specification 4.0 + LE
Supported Peripherals Temperature and humidity sensors, liquid level sensors, Inateck Barcode Scanner, universal BLE sensors
Physical Specifications
Dimensions 79 x 43 x 12 mm
Weight Approximately 54 g
Casing IP54-rated for dust and splash resistance
Mounting Flexible mounting options
Operating Environment
Operating Temperature -20°C to +55°C
Storage Temperature -40°C to +70°C
Operating Humidity 5% to 95% non-condensing
Certifications & Approvals
Regulatory FMC920-QJIB0: CE/RED, CITC, E-Mark, RCM, REACH, RoHS, TRA, SDPPI (POSTEL), SIRIM QAS, TRA
FMC920-QKIB0: Anatel, REACH, RoHS

Features

Inputs/Outputs 1 Digital Input, 1 Analog Input, 1 Digital Output
Sensors Accelerometer
Memory 128 MB internal memory (up to 8,000 records)
Advanced Scenarios Green Driving • Over Speeding detection • Jamming detection
GNSS Fuel Counter • DOUT Control Via Call • Excessive Idling detection
Unplug detection • Towing detection • Crash detection
Auto Geofence • Manual Geofence • Trip
Configuration and Firmware Update FOTA Web • Teltonika Configurator (USB/Bluetooth) • FMBT mobile application
Time Synchronization GNSS, NITZ, NTP
Ignition Detection Digital Input 1, Accelerometer, External Power Voltage
